Gleistein

GeoTwist® Polyester

Extremely durable, permanently flexible and attractively priced mooring line.

  • 3-strand laid construction made of HT Polyester
  • Thermally stabilized for higher service life and improved handling
  • Polyester fibres combine best abrasion resistance with outstanding UV stability
  • Remains flexible throughout its usable life
  • The light resistance of solid colour versions is even more superior than that of the white coloured version
  • Highly suitable as mooring line, towing spring or anchor warp

Load elongation curve

GeoTwist Polyester - Load elongation curve - Carl Stahl

Beschikbare kleuren

GeoTwist Polyester kleuren - Carl Stahl

Technische data

Ø (mm) kg / 100 m BI. real [daN]* BI. linear [daN]**
2


3


4 1,21 290 322
5 1,90 427 474
6 2,73 650 722
8 4,85 1.150 1.278
10 7,58 1.850
2.056
12 10,90 3.000 3.333
14 14,90 3.900 4.333
16 19,40 5.000 5.556
18 24,60 6.400 7.111
20 30,30 8.400 9.333
22 36,70 9.800 10.889
24 43,70 11.500 12.778
26 51,20 12.800 14.222
28 59,40 15.400 17.111
30 68,20 17.400 19.333
32 77,60 20.000 22.222
36 98,20 25.200 28.000
40 121,00 31.000 34.444
* Spliced break load | Elongation at 10% of breaking load
** Linear break load according to DIN EN ISO 2307 | Elongation at 4,0% of breaking load

Op rol, custom-made, serie werk of enkele stuks.

Neem
contact op

Bel ons op +31 (0)75 631 85 36 van maandag t/m vrijdag tussen 8:00 - 17:00u of stuur een e-mail naar benelux@carlstahl.com en wij nemen zo snel mogelijk contact met je op.

Wij adviseren jou graag!
